Toxic Storage Cabinet
Toxic cabinets are used in medicine and health, national defense technology, inspection and testing, industrial and mining enterprises, metallurgy and chemical industries to store and manage toxic and dangerous chemicals, toxic and dangerous drugs, valuable drugs and scientific research specimens and other items with high safety and insurance;
*Storage substances: narcotics and drugs such as ethanol, procaine, benzocaine, ketamine, benzyl alcohol, tubocurarine, etc.
SAFETY CABINETS
Safety Cabinets store flammable liquids, corrosives, pesticides and other hazardous materials. All fire-resistant safety cabinets by meet fire codes and regulations for safety storage.
To help protect your people and facility from a potential fire, safety cabinets are engineered to safely contain flammable fuels, solvents, and chemicals. Safety cabinets can not only help everyone store chemicals reasonably, save chemical supplies, but also save human resources, and avoid fires caused by chemicals with the greatest strength.
CLASSIFICATION
Toxic Storage Cabinet
Toxic cabinets are used in medicine and health, national defense technology, inspection and testing, industrial and mining enterprises, metallurgy and chemical industries to store and manage toxic and dangerous chemicals, toxic and dangerous drugs, valuable drugs and scientific research specimens and other items with high safety and insurance;
*Storage substances: narcotics and drugs such as ethanol, procaine, benzocaine, ketamine, benzyl alcohol, tubocurarine, etc.
SPECIFICATION
①The safety cabinet is constructed by double-wall 18 Ga (1.2-mm) steel sheet through spot welding, (38-mm) of insulating air space for fire resistance.
②Ventilation holes are set on the left and right sides to keep the air circulating in the cabinet and reduce the concentration of volatile toxic gases. You can choose to install ventilating pipes to remove toxic and harmful gases.
③Resin powder coating treatment, the surface is bright, dustproof, rustproof and moistureproof.
④The three-point linkage lock reduces friction or mechanical sparks and reduces static electricity accumulation.
⑤Cabinets feature a leakproof 2 in. (51-mm) bottom sump, dual vents with flame arresters.
⑥Galvanized steel shelves direct spills to back and bottom of a leakproof sump. They adjust on (80-mm) centers for versatile storage, the maximum load-bearing capacity of the shelf is 100kg, each shelf is 8cm apart. Additionally, they include PP trays that sit on top of galvanized steel shelves and a separate PP liner for the bottom sump to resist aggressive chemicals. Easily remove the liner for quick cleaning of drips and leaks. An all epoxy baked-on powder-coat finish, inside and out, provides increased chemical resistance.
⑦The continuous piano hinge makes the cabinet door close and open smoothly.
⑧The reflective warning labels are highly visible under fire conditions or during power outages when illuminated with a flashlight.
Model | Volume | Size(H*W*D)mm | NO.Door | Shelf Pcs | Shelf bearing |
TC-01 | 15L/4 Gallons | 560*430*430 | Single | 1 | 50Kg |
TC-02 | 38L/10 Gallons | 640*590*600 | Single | 1 | 50Kg |
TC-03 | 45L/12 Gallons | 890*590*460 | Single | 1 | 50Kg |
TC-04 | 83L/22 Gallons | 1650*600*460 | Single | 3 | 50Kg |
890*890*560 | Double | 1 | 50Kg | ||
TC-05 | 114L/30 Gallons | 1120*1090*460 | Double | 1 | 50Kg |
TC-06 | 170L/45 Gallons | 1650*1090*460 | Double | 2 | 100Kg |
TC-07 | 204L/54 Gallons | 1650*600*870 | Single | 3 | 100Kg |
TC-08 | 227L/60 Gallons | 1650*860*860 | Double | 2 | 100Kg |
TC-09 | 340L/90 Gallons | 1650*1090*860 | Double | 2 | 100Kg |
PRODUCT DETIALS
Fire and explosion vent Adjustable shelf PP trays Anti-static design of
three-point linkage lock
GA electronic combination lock Reflective label Automatic Door(Option)
double lock management
