EW-21
A combination emergency shower and eyewash station is cut out to flush harmful contaminants and pathogens out of the eyes and body in any environment, yet saves a lot of space. This combo merges a shower head and eyewash into one unit for a superior washdown and more even spray pattern.
Combination Eyewash Showers
EW-21
Combination Eyewash Showers
(Pull&Push Type)(Foot Treadle)
SPECIFICATION
Material: Stainless Steel 304
Surface finishing: sanded
Assembling feature: the allows easier pipe connection and disconnection
Usage: drenching body and rinsing faces / eyes can be operated separately or simultaneously
Shower&eye wash switch: SS304 ball valve
Shower head: spinning-formed with curled rim, diameter 250 mm
Pipe diameter: 38 mm
Nominal pressure: 1.0 Mpa
Working pressure: 0.2~0.4 Mpa
Testing pressure: 1.5 Mpa
Temperature requirement on working environment: 0°C~40°C
Flow rate of body shower: ≥76 L/min
Flow rate of eye/face wash: ≥11.4 L/min
Flow rate of eye wash: ≥1.5 L/min
Eyewash bowl features: 300 mm in diameter, vertical bowl-wall design, allows better water collecting and anti-splashing
Dust cover feature: integrated with the spray head (not connected by chain)
Spray head feature: patented design, each spray head equips with one water - flow control valve
Inlet thread: Rp1",female
Outlet thread: Rp1" ,female
Inlet height (from above the floor): 1570 mm
Outlet height (from above the floor): 90 mm
Distance between spray heads: 170 mm
Water pattern coverage: at the height of 1524 mm above floor, the water pattern covers a circular area of at least 510 mm in diameter.
Executive standard: ANSIZ358.1-2014 (American Standard)
