Flammable&Poison Storage Cabinet
Safety Cabinets store flammable liquids, corrosives, pesticides and other hazardous materials. All fire-resistant safety cabinets by meet fire codes and regulations for safety storage.
To help protect your people and facility from a potential fire, safety cabinets are engineered to safely contain flammable fuels, solvents, and chemicals. Safety cabinets can not only help everyone store chemicals reasonably, save chemical supplies, but also save human resources, and avoid fires caused by chemicals with the greatest strength.
SAFETY CABINETS
Safety Cabinets store flammable liquids, corrosives, pesticides and other hazardous materials. All fire-resistant safety cabinets by meet fire codes and regulations for safety storage.
To help protect your people and facility from a potential fire, safety cabinets are engineered to safely contain flammable fuels, solvents, and chemicals. Safety cabinets can not only help everyone store chemicals reasonably, save chemical supplies, but also save human resources, and avoid fires caused by chemicals with the greatest strength.
CLASSIFICATION
Flammable&Poison Storage Cabinet
SPECIFICATION
1. External construction: The cabinet is made of 1.2mm high-quality cold-rolled steel sheet, and the base is made of 2.0mm cold-rolled steel sheet. After pickling and phosphating, it is electrostatically sprayed and cured at high temperature. There are four Φ60mm moving wheels at the bottom of the cabinet, which is convenient for the storage cabinet to move.
2. Internal construction: The inner tank of the cabinet (upper, lower, left and right lining boards) are all made of pp sheet; the interior is equipped with a three-layer stepped pp movable shelf, and the board has a 5MM ventilation hole. The bottom layer of the inside of the cabinet is left with a leaking canal that can store no less than 120mm thick yellow sand, which is used for burying flammable items.
3. Hinge: Continuous smooth piano hinge, 180°opening. A fireproof expansion seal is installed between the cabinet door and the cabinet, and the cabinet is filled with special fireproof materials with thermal insulation effect.
4. Door locks: mechanical locks, anti-theft locks and LCD electronic code locks, to meet the requirements of double double lock management.
5. Air exhaust: There is a Φ110mm air outlet on the top of the cabinet, and an AC220V, 50HZ, 0.18A axial flow fan is built in the air outlet on the top of the cabinet, the maximum air volume is 300m/h, the speed is 2550 rpm/min, and the ambient temperature is (-10~+70) °C. There is an adjustable air inlet on the right side of the bottom of the cabinet, and the stainless steel adjustable air valve of corrosion-resistant material is set to open before the fan is turned on.
6. Time controller: Multiple time periods can be set for exhaust ventilation.
7. Temperature and humidity controller: The controller monitors and controls the temperature and humidity in the cabinet in real time, and the controller displays the set and measured values. Power supply AC220V±10% 50HZ, temperature control 0~99.9°C (user setting), humidity control 0~99.9%RH (user setting).
8. Alarm automatic exhaust: When the temperature and humidity exceed the set value, the sound and light alarm will alert and the automatic exhaust device will be activated to reduce the temperature and humidity inside the storage cabinet in time until the alarm state is lifted.
MODEL | DIMENSION (H*W*D)MM | COLOR | CINFIGURATION |
PSC-01 | 1200*900*510 | Yellow/Blue/Red | 2 shelves, double doors, password lock, time controller, temperature and humidity monitoring, fan |
PSC-02 | 1860*900*510 | Yellow/Blue/Red | 3 shelves, double doors, password lock, time controller, temperature and humidity monitoring, fan |
PSC-03 | 1980*900*510 | Yellow/Blue/Red | 3 shelves, double doors, password lock, time controller, temperature and humidity monitoring, fan |
PRODUCT DETIALS
Internal construction Hinge
Door locks Air exhaust
Time controller Temperature and humidity controller
Alarm automatic exhaust
